Pumps and hydraulics (1905)

Hawkins, N. (Nehemiah), 1833- · New York : Theo. Audel · leaf 29

An illustration from Pumps and hydraulics, 1905, leaf 29
Street Elbow. … Stud-bolt. A piece of round bar metal with a thread uponeach end. A represents thread for nut; B body of boltand C thread to fit in casting. IP

Hydraulic machinery · Pumping machinery
