Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)

Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 131

An illustration from Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator, 1920, leaf 131 — Fig. 101. Reversible Quarter-Twist—Two-Guide Pulleys have one common central plane, arriving at C, a point in thetrace of the central planes of M and P, and from leaving point Cto receiving point E. It will be noted that the center line of beltconnecting both leaving and receiving points* is always…

Machinery

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
