Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)
Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 240
e center of the machine—the shaft—and work outward,completing each part as it is reached. However, if we start withthe shaft, we soon find that we do not have sufficient data to com-plete the drawing. While the designer has given some data fromwhich we could start, as for instance the length… … 226 MACHINE DRAWING PLATE B. ARMATURE PUNCHINQS The armature laminations, Fig. 1, can very easily be drawn,since the designer has given all the necessary data as to dimensions,and it is only necessary for the draftsman to put this data on adrawing for the use of the shopman. Details of Slots. It…
