Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 244
the relation on the sheet that the laws of projection require,but nothing in clearness is sacrificed, space is saved, and the drawingis really made easier to read. In addition to showing all necessary details of the coils, suf-ficient data is given from which to make the next drawing. Inother… … 230 MACHINE DRAWING PLATE D. ARMATURE FLANGES AND SPIDER We come logically then to the armature flanges and the spider. Difference Between Front and Back Flanges. The two flangesare quite similar in everything except as regards their mountingon the spider. The one for the back end of the armature,…
