pe in the other direction, crossing the other lines, and to drawthem in would obviously cause confusion. Connecting Rod. Fig. 38 shows the connecting rod for a smallsteam engine. This piece calls for little comment. The outlines ofthe crank pin and cross-head pin are shown in dot-and-dash… … Fig. 3S. Detail of a Connecting Rod should be carefully noted by the student, that any such informationwhich can be given on the details, without confusing the drawing,to tie up one detail with another, is usually good practice. It notonly saves time in the drafting room in checking and general…
