Fig. 101. Reversible Quarter-Twist—Two-Guide Pulleys have one common central plane, arriving at C, a point in thetrace of the central planes of M and P, and from leaving point Cto receiving point E. It will be noted that the center line of beltconnecting both leaving and receiving points is always…
