Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)
Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 126
ding of belts; i.e., thecenter line of the belt, onleaving the driving pulley,is delivered into the cen-tral plane of the receivingpulley. Examining the figure,we find that the center lineof the belt moves in direc-tion of arrow from L1 toR, and around pulley B to L2, from L2 on the surface of B to… … Fig. 97. Diagram of Pulley Drive where ShaftsAre not Parallel 114 MACHINE DRAWING
