nd S are the two mainpulleys, and C and D arethe two guide-pulleys. Theline X Y is the line of inter-section of the planes of the main pulleys. The location of theguide-pulleys is sufficiently clear from the drawing, without furtherexplanation. Fig. 105 shows the arrangement when the main pulleys…
