Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)
Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 137
and S are the two mainpulleys, and C and D arethe two guide-pulleys. Theline X Y is the line of inter-section of the planes of the main pulleys. The location of theguide-pulleys is sufficiently clear from the drawing,without furtherexplanation. Fig. 105 shows the arrangement when the main pulleys…
Machinery
