Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)
Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 138
Fig. 104. Belt Drive for Same Sized Pulleys, Shaftsnot Parallel but in Same Plane. MACHINE DRAWING 125 M*» … in Fig. 104. In the elevation, the upper guide-pulley, which receivesthe belt from S, has its central plane tangent to the pulley S at thepoint where the belt leaves S, as shown by the line AVBV. Thelower guide-pulley, which receives the belt from R, has its centerplane tangent to R, as shown by…
