Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 215
pt constantly in mind, the student will have notrouble in building up the detailed design. This fundamental conception of a complicated piece is a veryimportant idea, and should be developed carefully by the student.It is one of the great secrets of good design, both from an artisticand a… … MACHINE DRAWING 203 prevailing shape to the structure, no harmony of the lines. This isbecause the designer, if he may be so called, did not have the funda-mental notion of shape, to which all minor details should have beensubordinated. He simply grouped parts together, without con-sidering the…
