Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 238
o size and number of conductors in fieldsand armature, the size and arrangement of slots in the armaturelaminations, and the kind of insulation and its arrangement. Fromthis data the draftsman must make his drawings complete in everydetail, so that the machine can be built in the shops. The… … 224 MACHINE DRAWING PRELIMINARY LAYOUT SKETCH Pencil Sketch. The designing draftsman may make firsta sketch or preliminary drawing showing the outline of the machine,with such dimensions as may be determined from the designers data. PLATE A. GENERAL OUTLINE DRAWING Plate A shows such a preliminary…
