Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)
Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 278
ntirely unnecessary from the standpointof manufacturing the various parts of the machine, but is indis-pensable to the man who assembles the machine either in the factoryor during installation. This drawing is laid out along the samelines as Plate A except that more detail is included and the… … 264 MACHINE DRAWING constructed and bolts set, even if the machine had not beenreceived. Coupling Details. Another point which is given in detailis the coupling for attaching the machine to the prime mover. Itwill be noted that the dimensions of this coupling have been givenin inches taken from the…
