Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 247
mand all dimensions, Fig. 1. A note giving insulation data is added,the thickness being given as usual in mils or thousandths of an inch. Assembly Drawing. From the above an assembly is devel-oped, Fig. 6, showing the rings in place under the armature coilsand supported by a ring attached to the… … Insulate with 2 layersof varnished cambriccovered with bre/men drill. Stress on bands -18 IS lbs.Tension on P.B. Wire. 340 to 380 lbs.
