Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 254
coupling which will be furnishedby the manufacturer of the prime mover to which the machine isto be coupled. The keys are called for in the title table by dimensions, noother information being necessary. It will be noted that only enough of the sections of armaturespider and commutator shell are… … 240 MACHINE DRAWING PLATE H. MAGNET FRAME AND BASE General Details. The details of the magnet frame are coveredby Plate H. Certain dimensions here are fixed by the electricaldesign in order to give the proper amount of iron in the frame,the proper size field cores, and proper spacing of fields. The…
