Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)

Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 275

An illustration from Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator, 1914, leaf 275
ion of the machine andan elevation of each of the terminal blocks on the side of the magnetframe. The detailed drawings of the fields, Plate J, and of the busrings Plate L, and the amount of current to be carried determinethe size and number of bars or cables which should be used for thevarious…
