ntal center line through cam at M. With CM as aradius draw a circle. Divide rise of follower in parts to give harmonicmotion. Divide one half of the circle just drawn into as many equalparts as there are spaces in the rise, and draw tangents at each point asshown. With C as a center draw an arc… … Fig. 216. Cam with Lever Follower. 124 MACHINE DRAWING 173. When levers are used to transmit motion from the cam, Fig. 216, the method of solution is similar to the previous cases. Giventhe center of the cam shaft, center of bell crank shaft, lengths of arms andtravel required at end of long arm as…
