Machine drawing; a text and problem book for technical students and draftsmen (1921)
Svensen, Carl L. (Carl Lars), 1884- · New York, D. Van Nostrand company · leaf 195
ead is used. PROB. 150, Fig. 308.—From the sketch make a complete working drawing for thePISTON. Supply complete dimensions. PROB. 151, Fig. 309.—Make a complete working drawing of the FLY WHEEL.Show one view in secticfn. PROB. 152, Fig. 310.—Make a complete working drawing of the BASE. Showfront… … -Polish Fig. 307. Prob. 149. Cylinder Head.
Machinery
