/^bur imperfecf fhreods i fu// af roofs [-« .30 yX-—.P3 y\* Complefe fhreods .69 Fig. 35. Enlarged Section of 2\ Pipe Thread. Pipe threads have an angle of 60°, and have the top and l^ottom of theV rounded. The threads are cut on a taper of three fourths inch perfoot. The form is shown in Fig. 35.…
