t~ X) — m — ^ — to - w -_ - Fig. 110. Locomotive Piston. MACHINE DETAILS 77 A form of locomotive piston is shown in Fig. 140. It is a steel castingfor lightness and of conical form for strength. A gas engine piston isillustrated in Fig. 141. … Fig. 141. Gas Engine Piston. 115. Crossheads are used on steam engines, pumps, air compressorsand many other machines. Two types of crossheads are shown inFigs. 142 and 143, with the names of the parts. The body of the cross-
