Machine drawing; a text and problem book for technical students and draftsmen (1921)
Svensen, Carl L. (Carl Lars), 1884- · New York, D. Van Nostrand company · leaf 89
Fig. 144. Connecting Rod End. is generally made for adjusting the distance between the centers of theends. The rod itself may have a circular, elliptical, rectangular, I- … FiG. 145. Connecting Rod End. shape, or other form of cross section. Types of connecting rod ends areshown in Figs. 144, 145 and 146.
Machinery
