Machine drawing; a text and problem book for technical students and draftsmen (1921)
Svensen, Carl L. (Carl Lars), 1884- · New York, D. Van Nostrand company · leaf 94
Fig. 155. Stuffing Boxes. MACHINE DETAILS 83 The gland stuffing box is used for rods IV2 and more in diameter.The names of the parts are given on Fig. 155. The box should be deepenough for at least four strands of packing and the gland proportioned so … Stuffing Boxes. as to compress it to about one half its original length. The box andgland may be either flat or bevelled. If lined with composition thelining should be at least Vie thick, but for small rods (less than 2diameter) it is generally advisable to make the gland either all brass orcast…
