Machinery and processes of the industrial arts, and apparatus of the exact sciences (1869)
Barnard, Frederick A. P. (Frederick Augustus Porter), 1809-1889 · Washington, Govt. print. off. · leaf 133
Schieles Turbine. directrix for the water but the tube of supply. Its construction will beunderstood by referring to the figures. It is enclosed in a cylindrical boxwhich is open both above and below, and which serves only to guide the 116 PAEIS UNIVERSAL EXPOSITION. water as it enters by the… … Scbieles Turbine—plan. Fisf. 34.
