Machinists' and draftsmen's handbook, containing tables, rules and formulas, with numerous examples explaining the principles of mathematics and mechanics as applied to the mechanical trades; intended as a reference book for all interested in mechanical work (1910)
Lobben, Peder, 1858- · New York, D. Van Nostrand company · leaf 259
gular beam supported under both ends andloaded at the center, fig. 8. 4X CX H2 X B A rectangular beam supported under both ends and loadedevenly throughout its whole length will carry twice the load of 240 STRENGTH OF MATERIALS. a beam supported under both ends and loaded at the center;therefore,… … Each letter in these formulas has the same meaning as informula for Fig. 6, page 239, and each formula may be transposedthe same as that formula. The most convenient way is, in eachcase, to multiply the numerical value of Cfrom Table No. 30, byits proper coefficient according to mode of loading,…
Mechanical engineering
