line on avalve-path diagram where the port is kept fully open,the crank still traveling on, and approaching the timefor the cut-off to be effected. The lever E is in thebest position to act as a lever at the same time that itscenter is completing its movement in the slot JK, andis commencing to… … 29S LOCOMOTIVE ENGINE RUNNING. RULES FOR LAYING DOWN THE CENTER LINES OE THEMOTION. Lay down the center line aa (Fig. 29) of the cyHnder,and that of the valve-stem bb, at the relative distancesrequired for the engine to which the application is to bemade ; the valve-stem center line being, however,…
