The machinist and tool maker's instructor, containing an easy method of calculating and laying out difficult work in the machine shop .. (1896)

Genung, Edward. [from old catalog] · New York [Press of J. B. Savage, Cleveland] · leaf 29

An illustration from The machinist and tool maker's instructor, containing an easy method of calculating and laying out difficult work in the machine shop .., 1896, leaf 29 — ^//, or more, in length,depending upon the accuracy of the forging. There is also alittle waste in the forging of anything in the fire, but thatdoes not usually amount to much on small pieces. Figure 6 is 1%; X m and w long; what is the contents in cubic inches ? 3.52.5 17 5 70 8.755.5 square… … 48.125 cubic inches. Figure 8 represents a round ball, say 4% in diameterWhat is the number of cubic inches in the ball ? THE MACHINIST AND TOOL MAKERS INSTRUCTOR. 25 Cube the diameter and multiply by .5236 : 4.254.25 s& s
