Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 239
Fig. 760.—Dog used for Fig. 761.—Bitch used forBuilders Gantry. Builders Gantry. latter showing three different methods ofcutting the braces in general use. Fig. 759illustrates an impost piece, used for the pur- Fig. 762 … Fig. 763. Fig. 762.—Method of Finishing End of Fender of Builders Gantry. Fig. 763.—Enlarged View of Cleat for Builders Gantry. pose of giving a greater bearing surfacewhere a joint occurs in the head. Fig. 757 GANTRIES, STAGING, AND SHORING. 217 ! illustrates two methods of sheeting. If theI 9-in.…
Carpentry · Joinery
