A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)

Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 277

An illustration from A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc., 1878, leaf 277 — B is the stuffing box,C C the gland. D D the piston rod, rr a brass plate with anexternal groove and six to eight radial holes,/ the pack-ing, g a copper pipe communicating with the groove, k theoil cup, and Ji a cock, which is only opened when the ma-chine is at rest. The cylinder should finally… … kolben), which moves back and forth in the cylinder (com-pare § 300), and is then transferred to the piston rod. Thepiston consists of a short cylinder very exactly fitted tothe steam cvlinder, and consists essentially of three parts § 443-] THE STEAM EXGIXE. 263 —the piston stock, the packing, and…
