A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)

Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 29

An illustration from A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc., 1878, leaf 29 — balls. If the more expansible metal strip is beneath, thenthe spring will curve upward, when the temperature in-creases, and as simultaneously the bar C L becomes longer,and therefore the distance of the bob L from the point ofsuspension becomes greater, it is possible so to adjustthings that the…

Mechanics, Applied · Mechanical engineering

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
