A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)

Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 292

An illustration from A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc., 1878, leaf 292 — out as much up asdown, and the force necessary for lifting it is but small.When completely lifted (see II.), the steam can enter, be- § 450.] THE STEAM ENGINE 270 tween a and b and c and d, the space A, and from therepasses through B to where it is needed. The construction of such a bell valve is…

Mechanics, Applied · Mechanical engineering

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
