A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)

Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 297

An illustration from A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc., 1878, leaf 297 — . In general, thisintermediate machinery consists: 1. Of a crank (Fr. manivelle ; Ger.Kurbel) (see § 142). 2. Of a connecting rod (Fr. bielle ;Ger. Kurbelstange). 3. Of a flv-whecl (Fr. volant; Ger.Schwungrad). The crank CA, Fig. 71/], forms a partof the shaft C, and is joined to the piston rod DF… … §452.] STEAM-GENERATING APPARATUS. 28J head B may not be drawn to one side by the connectingrod, it is made to move between guides, and in order thatthe crank shaft C may not experience sudden changes ofvelocity owing to the variable action of the connecting rod,a fly-wheel (see §111) is attached…

Mechanics, Applied · Mechanical engineering

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
