A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 301
Fig. 722. … B D are connected by a cross-head BAB, and this againwith another cross-head E by a third rod A E, which runsin vertical guides between the two cylinders, and is alsoconnected with the connecting rod KE. §453-] S TEA M- GEXERA TING A PPA RA T US. 289 Fig. 723. In Fig-. 723 is a sketch of a…
