fall into this slot. By this operation, the steam is ad-mitted to the opposite chamber of the steam cylinderand changes the stroke of both the steam piston andregulator. This reversion may be more simply accom-plished by the use of Stephensons link motion, thearrangement and working of which will… … representation in Fig. 729 of a Watt low-pressure engine:the figure also gives a clear idea of a complete engine andits essential parts. A is the steam or working cylinder, B 294 HEAT, STEAM, AND STEAM ENGINES. [§455- the steam or driving piston, and C the steam box fromwhich the steam from the…
