Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc (1917)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Textile Pub. Co · leaf 194

An illustration from Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc, 1917, leaf 194
s to the shuttle racks andshuttles move them to communicate to said racks andshuttles a complete movement in one direction. Atthe end of the latter, the continued rotation of thecrank shaft 1, through gear 2 and gear 3 carrying Looms and Devices. 181 the crank pin 7, connected by the arm 8 to the… … Fig, 232 position shown by broken lines in said figure and leavethe gears 4 and 6 substantially at rest and thus causea dwell after each half rotation of the gear 6 at theend of each movement of the shuttles and shuttleracks, as the lay beats up. With one end of the belts 11 and 12 attached toa…

Weaving · Textile fabrics

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
