Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc (1917)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Textile Pub. Co · leaf 208

An illustration from Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc, 1917, leaf 208
eys, so as to produce the required friction onsaid web during weaving. Take-up pulleys C are fitted loose on shaft B andare each held in position longitudinally thereon by anouter collar (not shown) and an internal hub H, bothsecured to shaft B. Upon each hub H are mountedat opposite sides of the… … Fig, 244 The normal positions of the pawl a are in engage-ment with the thus mentioned corrugated surfaces ofpulleys C, being held in engagement by said springs c,one end of which is attached to hub H, and the otherto the pawl. The inner ends of said pawls a areprovided with extensions to engage…

Weaving · Textile fabrics
