sance ladder incourse of erection. 3. Double tripod scaffold fortheodolite and observer. fieconnaissance ladder and beacon.Service Geographique de VArniee. Designed by Commandant L. Ditrand,11 Rcpinient dAriillerie. TOPOGRAPHICAL SURVEY 137 a chain should start from one base and close on another.… … Fig. 18. Diagram of Geodetic Triangulation up the Nile Valley from Cairoto Beba. The two heavy lines are bases. Beacons. Beacons are of two principal kinds : the luminous and theopaque. In most countries, when the ray is more than eight ornine miles long it is necessary to use luminous beacons or…
