Marine engine indicating; a complete treatise on the indicator and indicator diagrams as applied to marine engines (1910)

Linch, Charles Sutterley, b. 1869 · Boston, American Steam Gauge and Valve Mfg. Co. · leaf 107

An illustration from Marine engine indicating; a complete treatise on the indicator and indicator diagrams as applied to marine engines, 1910, leaf 107 — M. E. P. I. H. P. Steam 220. H = 122.55 H = 2,561.84 M. P. Rec 61. M = 41.10 M = 2,471.60 L. P. Rec. ...... 10.5 L = 11.74 L =2,360.95 Vacuum 25. Total, 7,394.39 R. P. M 75. Piston Speed 7S7.5 Cut off: H. P. = .69, M. P. & L. P. = .75 102 MARINE INDICATINGSeries 4

Indicators for steam-engines · Marine engines
