Marine engine indicating; a complete treatise on the indicator and indicator diagrams as applied to marine engines (1910)
Linch, Charles Sutterley, b. 1869 · Boston, American Steam Gauge and Valve Mfg. Co. · leaf 56
PERFECT VACUUM … 54 MARINE INDICATING ceed to treat the diagram from M. P. cylinder and L. P. cylinder, inprecisely the same manner. Fig. 21 shows the diagrams of Fig. 20divided, and the corresponding pressure inserted. The combined diagram is shown on plate 2. The method of construction is as follows: Draw a…
Indicators for steam-engines · Marine engines
