Babendreier, Arthur O. [from old catalog], Maryland institute for the promotion of mechanic arts and design, Baltimore. [from old catalog] · Baltimore, Md., The Maryland institute for the promotion of mechanic arts and design · leaf 51
ase circle. An involutecurve starting from thepoint of intersection be-tween the base circle and INVOLUTE. i« e r i —— line of centers lorms the curve for the addendum, or face, and part of the deden-dum, or flank, of the gear tooth, respectively, of eachwheel. The balance of the flank, or to the… … Power Transmission 49 tangent one to the other. Also 24 cutters of each pitchare required to cut gears ranging from 12 teeth to a rack. Involute teeth are considered stronger and the pitchcircles need not be exactly tangent one to the other forgood operation. Again, only 8 cutters are required to…
Mechanics
