Measurement of vessels for the Panama canal (1913)

Johnson, Emory R. (Emory Richard), 1864-1950, United States. War Dept · Washington, Govt. Print. Off. · leaf 277

An illustration from Measurement of vessels for the Panama canal, 1913, leaf 277 — bb < J aa. E = space exempted. M = space measured. Fig. 7.—Bridge. … bb > i aa.od < j aa.ed < J aa.ff< J ee\ E = space exempted. E = light and air and funnel space in lowest tier of erections, measured under Art. IV, Sec. 3.M = space measured.M = closed house, measured. MEASUREMENT OF VESSELS FOE PANAMA CANAL. 229 Fig. 8.—Poop and Bridge with interval…

Huebner, Grover Gerhardt, 1884 · Ships · Tonnage · Navires

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
