Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 147

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 147
away that it shall be two units distantfrom the upper end of the stick. Thebalance, or belly band, CC, whose accuracy contributes much to thestabihty of the whole in the air, consists of a string fixed at one endto the junction, D, of the bow and stick, and at the other to the stickitself at a… … AIR-POWER MOTORS AND APPLIANCES. 147 at K in such a way as to cause the bow to curve backward. Thiscurvature is increased or diminished according to the force of the wind.Nothing remains to be done but to attach the cord to the balance,or belly band, and raise the kite. 361 THE EDDY TAILLESS KITE.…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
