Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 20

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 20
MECHANICAL POWER, LEVER. 19 … 5. LEVER NIPPERS. A labor-saving device in the hands of the wireworker. Its lever advantage is readilyseen by inspection of the detailed partsas a compound lever, which doubles thecutting power of the nippers. SECTION 11. TRANSMISSION OF POWER. Section II. TRANSMISSION OF POWER.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
