Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 201

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 201
also fordischarging the aerial and submerged torpedoes. 200 NAVIGATION, VESSELS, MARINE APPLIANCES, ETC. 506. REVERSING CLUTCH for a launch. C is the propellershaft ; D, the engine shaft ; A, H, shell keyed to the propeller shaft, with an inside spurgear to match thering of pinions J ;L, anchor… … ij^^-^. 507. ICE BOAT. Plan and elevation drawn to a scale, as shown inthe engraving. Figuredmeasures are given for themost important parts.

Mechanical movements
