Twentieth century hand-book for steam engineers and electricians with questions and answers; a practical non-technical treatise .. (1913)

Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 859

An illustration from Twentieth century hand-book for steam engineers and electricians with questions and answers; a practical non-technical treatise .., 1913, leaf 859
he internal construction of this type of air compressors. 834 Steam Engineering each part being numbered and the designation of the partsgiven in the caption. The Meyer cut-off valve gear is clearly shown in thesteam end, and the Ingersoll-Sargeant piston inlet valvesare shown in the air cylinder,… … Fig. 350ingersoll-sergeant piston inlet valve cylindeb The standard governor for all Class A compressorsis the type known as the Air-BalV Governor. Unloader and Regulator,—Th^ function of the unloaderand regulator is to take the load off the air pistonwhen the pressure reaches, the desired point,…

Steam engineering · Electrical engineering · Steam turbines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
