547. AUTOMOBILE STEAM EN-GINE. A two-cylinder engine of thelocomotive type with Hnk motion and Dvalves ; cylinders 2 J x 4 inches. Boilerpump operated by a lever and link froma crosshead of one of the cylinders.Extreme cut-off o to f. The sprocket wheel on the shaft be-tween the eccentrics connects… … 548. TYPES OF MOTOR BI-CYCLES. The Derby. A chainfrom the motor drives a frictionwheel which is pressed on the tireby a bell-crank lever. This arrange-ment allows of instantaneous motordisconnection.
