Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 252

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 252
654. FRICTION-PLATECLUTCH. In this model theplates are pressed into V-shapedrings with perforations for lubrica-tion. Ihe V shape allows of agreat friction with Hght pressure onthe clutch lever. Alternate V plates are fixed toouter shell by their mortised edges,and the intervening plates to… … 656. FRICTION CLUTCH. Browntype. The usual sliding sleeve on theshaft and connection to an arm on aright and left double-thread screw, whichexpands the friction blocks and so clutchesthe inner face of the pulley rim.
