Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)

Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 420

An illustration from Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles, 1906, leaf 420 — g or lowering pin, P;X, an internal gear on disc, B; Y, a groove containing perforations for ad-mitting pins, P, when H and B are locked together. TYPICAL GASOLINE CARRIAGES. 407 internal gear will be held in a fixed position and the motion ofthe motor will cause the planet gears, A, to roll around… … Fig. 314.—Front Elevation of the Duryea Change Speed Gear. The letteringhere refers to the same parts as in the previous figure. N marks theposition of the lever, M, when pins, P, are inserted in holes. Y, in D.M marks the position of lever, M, when pins. P, are raised from holesin D. R and R, arms…

Automobiles

Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
