Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 294

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 294
764. BELT-DRIVEN FORG-ING HAMMER. Bradley type.The hammer in guides is oper-ated by an elastic strap attachedto the yoke of a helve vibratedby elastic cushions and an armwdth adjustable connecting rodto an eccentric on the belt shaft. The treadle controls the blowof the hammer by a frictionbrake. … 765. EYE-BENDING MA-CHINE. A hand-operated ma-chine which grips the end of thewire against the central pin by theupper lever, when the lower lever isswung around against the stop andthen forming the reverse bend bythe treadle and push bar.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
