An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 297
ocks sur-rounding the tire are set up by hand screwsand a wrench, compressing the tire tightlyupon the wheel. 296 MILL AND FACTORY APPLIANCES AND TOOLS, ETC. 778. HYDRAULIC TIRE-SETTING MACHINE. A number ofcylinders and pistons set within a strong iron ring compress the tire upon the wheel by… … 779. AUTOMATIC FURNACE for hardening and tempering balls.The balls are picked up by the small shelf in the revolving hop-per, and tipped into the mouth-piece, and carried along by thecentral screw ; transferred intothe outer and hotter reversescrew carrier to the chute, anddropped into a water…
