Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 300

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 300
776. METAL BAND-SAW. The modern metal band-saws are made tocut solid bars, such as center cranks,Ys in connecting rods and locomo-tive frames, as well as structural formsof all kinds. … 777. HAND-SCREW TIRE-SET-TIN G MACHINE. The blocks sur-rounding the tire are set up by hand screwsand a wrench, compressing the tire tightlyupon the wheel. 296 MILL AND FACTORY APPLIANCES AND TOOLS, ETC. 77S. HYDRAULIC TLRE-SETTIXG MACHINE. A number ofcylinders and pistons set within a strong iron…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
